Drivers & FirmwareWindows
No driver is necessary to install for Windows computers. However an ASIO driver is available at https://support.hercules.com/en/product/djcontrolinpulse200
If the ASIO driver is not installed, VirtualDJ will use the WASAPI driver in Audio setup.Mac OSX:
No driver is available or necessary to install for Mac OSX computers.The OS will install the necessary drivers first time the unit is connected to the computer.Firmware:
(for both Windows & Mac) No firmware update is available at the time this manual was written, but it is advised to check for any updates at Hercules Support Center https://support.hercules.com/en/product/djcontrolinpulse200
VirtualDJ 8 SetupDownload and install VirtualDJ 8 from http://www.virtualdj.com/download/index.html (in case you have not done already)
Once VirtualDJ 8 is launched, a Connect Window will appear to choose one of the available ways to login.
A Pro Infinity, a Pro Subscription or a PLUS License is required to use the Hercules DJControl Inpulse 200. Without any of the above Licenses, the controller will operate for 10 minutes each time you restart VirtualDJ.
A detection window will appear next verifying the proper connection.
Click on the Use Soundcard button to allow VirtualDJ to auto-create the pre-defined audio configuration.
Click to OK
The unit is now ready
The unit should be visible in the CONTROLLERS tab of Config and the “factory default
” available/selected from the Mappings drop-down list. The factory default Mapping offers the functions described in this Manual, however those can be adjusted to your needs via VDJ Script actions.
Find more details at http://www.virtualdj.com/wiki/VDJ8script.html
The unit has a pre-defined Audio configuration and a special button in the AUDIO tab of Config to provide that. The default audio configuration requires speakers to be connected at the rear-side Master
RCA sockets and headphones at the front panel 1/4" socket.
Refer to VirtualDJ 8 Manual for alternative audio configurations http://www.virtualdj.com/manuals/virtualdj8/settings/audiosetup.html
For further software settings please refer to the User Guide of VirtualDJ 8. http://www.virtualdj.com/manuals/virtualdj8/index.html
